Centerless Grinder

Buy Used Centerless Grinder from Lidkoping of year - 1992, Model - CL-630

SKU : 2505410
Used Lidkoping Centerless Grinder 1992 CL-630

Price : RFQ

CONTACT SELLER

Machine overview

Machine Specifications

  • Diameter 610 mm
  • Wheel Width 300 mm

Machine Description

  • Electrics Rebuilt Year 2015
  • Maximum opening between new wheels 150 mm
  • Recommended working range 5–125 mm
  • Recommended working range for bar grinding 25 mm
  • Maximum workpiece length for infeed grinding, normal wheels 295 mm
  • Maximum workpiece length for infeed grinding, recessed wheels 405 mm
  • Outer diameter of new wheel, standard/maximum 610/630 mm
  • Outer diameter worn wheel 380 mm
  • Nominal width 304.8 mm
  • Maximum width, with recessed wheel 400 mm
  • Bore diameter 304.8 mm
  • Peripheral speed max 63 m/s
  • Resolution, servomotor (grinding wheel headstock) 0.1 µm
  • Max. feed rate, servomotor (grinding wheel headstock) 20 mm/s
  • Regulating wheel diameter, new wheel, standard/maximum 330/380 mm
  • Outer diameter worn wheel (regulating wheel) 255 mm
  • Nominal width (regulating wheel) 150 mm
  • Maximum width, with recessed wheel (regulating wheel) 400 mm
  • Resolution, servomotor (headstock) 0.1 µm
  • Bore diameter (regulating wheel) 203 mm
  • Speed (regulating wheel) 10–750 rpm
  • Regulating wheel’s maximum inclination 6°
  • Main motor 37/100 kW
  • Height from floor to spindle centers 1060 mm
  • Footprint 6000 x 2800 mm
  • Net weight 11,500 kg
