This machine not available

EDM -Wirecut

Buy Used EDM -Wirecut from AgieCharmilles of year - 2006, Model - Vertex 3

SKU : 2405389
Used AgieCharmilles EDM -Wirecut 2006 Vertex 3

CONTACT SELLER

Machine overview

Machine Specifications

  • Length 500 mm
  • Width 350 mm

Machine Description

  • X-axis 500 mm
  • Y-axis 350 mm
  • Z-axis 256 mm
  • U/V axis +/- 70 mm
  • Capabilities
  • Maximum Taper 30° at 100 mm height
  • Maximum Workpiece Dimensions 1050 x 650 x 250 mm
  • Maximum Workpiece Weight 400/800 kg
  • Achievable Surface Quality Ra: 0.05 µm
  • Available Wire Diameters 0.07 - 0.33 mm
  • Features
  • Water Bath Machine with Automatic Wire Threading
  • Automatically Lowerable Container (Accessible from 2 Sides)
  • AGIEJOGGER Hand Box for Convenient Set-Up
  • AGIESETUP 3D
  • AGIEVISION 5 Control Unit
  • AGIE IPG-V Generator
  • Dimensions and Weight
  • Dimensions (L x W x H) 2800 x 2400 x 2220 mm
  • Net Weight 4500 kg
  • Condition and Services
  • Condition Completely cleaned, overhauled, and extensively tested.
  • Additional Services
  • Individual test on the Vertex 3
  • User training at Techma on your overhauled machine
  • Optional Services
  • Transportation
  • Commissioning
  • Cooling Unit
  • Clamping Devices
  • Consumables
