This machine not available

Grinder - Cylindrical

Buy Used Grinder - Cylindrical from Tripet of year - 1997, Model - TST 50 2R

SKU : 2404386
Used Tripet Grinder - Cylindrical 1997 TST 50 2R

CONTACT SELLER

Machine overview

Machine Specifications

  • Swing 50 mm
  • Centre Height 102 mm
  • Between Centre 100 mm

Machine Description

  • TECHNICAL DETAILS
  • Sanding diameter 0.5 - 50 mm
  • Sanding length 100 mm
  • Workpiece headstock
  • Center height 102 mm
  • Workpiece spindle nose W20
  • Mounting weight 20 kg
  • Shape accuracy <0.0005 mm
  • Speed 45 - 1500 rpm
  • Longitudinal adjustment 100 mm
  • Longitudinal slide / Z-axis
  • Travel range 300 mm
  • Drive AC motor
  • Resolution 0.0005 mm
  • Programming 0.0005 mm
  • Traversing speed 0 - 9 m/min
  • Cross slide / X-axis
  • Travel range 35 mm
  • Drive AC motor
  • Resolution 0.0001 mm
  • Programming 0.0001 mm
  • Travel speed 0 - 2 m/min
  • Cross slide / U-axis
  • Travel range 100 mm
  • Drive Manual adjustment
  • Resolution 1 graduation mark = 0.01 mm
  • Swivel slide / B-axis
  • Swivel range -30° / +60°
  • Drive Manual
  • Grinding headstock / T-axis
  • Hfz. Spindles T1, T2
  • Speed 15,000 - 150,000 rpm
  • Adjustment options ± 5°
  • MACHINE DETAILS
  • Connected load 20 kVA
