Buy Used Thread Milling from Wanderer, Model - GF 327 x 7000

SKU : 2307329

I am a dealer

Subscribe for similar machines

max. workpiece diameter 600 mm
threading length 7000 mm
max. module 8 / 12
min. module 1
swival range +/- 90 / 115 °
diameter of hob 63 - 140 mm
spindle turning speed - stepless 45 - 450 U/min
total power requirement kW
weight of the machine ca. 12,5 t
dimensions of the machine ca. 9,0 x 2,0 x 2,2 m
Condition In good condition, checked and partially overhauled by a specialist.
The existing milling head was replaced by an overhauled universal milling head.
Differential for inclined machining
Automatic indexing device (indexing discs changeable!) For multi-wedge,
multi-thread parts, then extensive bushings, support rollers and around 70
Change gears.
Conversion of the milling head speed to a frequency converter with corresponding
powerful motor is a great thing and saves a lot of set-up time.
Around 70 change gears, 3 bushing sticks of different sizes, around 20
Bushings, 2 roller mountings, 2 tips for direct mounting on the
Clamping spindle, 350 mm chuck, 2 spare part disks.
