Power Press

Buy Used Power Press from Fukui of year - 1984, Model - MTE800TF

SKU : 2506228
Used Fukui Power Press 1984 MTE800TF

Price : $520,000

CONTACT SELLER

Machine overview

Machine Specifications

  • Force 800 Ton
  • Stroke 600 mm

Machine Description

  • 800 Ton Transfer Press + 150 Ton Blanking Press
  • Stroke 600 mm
  • SPM (2D) 10–25
  • SPM (3D) 10–22
  • Die Height 950 mm
  • Slide Adjustment 50 mm
  • Slide Size 5400 × 1200 mm
  • Bolster Size 5430 × 1200 mm
  • Bolster Thickness 240 mm
  • Main Motor 150 kW, 400V, 50Hz
  • Balance Capacity 11 Ton
  • Max Drawing Depth (3D) 170 mm
  • Transfer Device
  • Number of Stages 8
  • 1st & 2nd Stage 10 Ton
  • 3rd, 4th, 5th, 7th Stage 20 Ton
  • 6th & 8th Stage 5 Ton
  • Blanking Press
  • Stroke 100 mm
  • SPM 10–25
  • Die Height 320 mm
  • Slide Adjustment 50 mm
  • Slide Size 1200 × 1000 mm
  • Bolster Size 1200 × 1000 mm
  • Coil Feeder
  • Thickness 0.8–2.3 mm
  • Width 200–610 mm
  • Coil Weight Up to 3 Tons
  • SPM 10–25
  • Coil Outer Diameter 1200 mm
  • Coil Inner Diameter 508 mm
